The HiViLux® Tension motorized screen with the grey HiViGrey Cinema 0.8 surface combines modern projection technology with an elegant, high-quality design. The universal grey surface is primarily intended for standard-throw and long-throw projectors and provides improved black levels compared with a white screen. It is also compatible with UST projectors when dedicated CLR performance is not required. For RGB triple-laser projectors where visible laser speckle is the main concern, HiViGrey Cinema 3L is the more suitable choice.

Perfect flatness thanks to Dual-Tension

The special dual-tensioning system works horizontally and vertically, ensuring a permanently flat, wrinkle-free image surface – without waves. Ideal for precise geometry, clean edges, and demanding home cinema installations.

HiViLux TXN tension motorized screen with HiViGrey Cinema 0.8 in a home cinema
HiViGrey Cinema 0.8 – controlled reflection for high image quality

The HiViGrey Cinema 0.8 technology (Gain 0.8) is designed for modern 4K and 8K projectors and offers excellent color reproduction with controlled reflection behavior – for high-contrast, brilliant images.

RF radio control & casing in black or white

The robust aluminum casing is available in black or white and blends harmoniously into any room aesthetic. The integrated RF radio system allows reliable control up to 20 m range – even without direct line of sight.

Installation & adjustment

Continuously adjustable drop height: The drop can be set continuously from 0 up to the maximum drop height, and the selected extension position can be saved. The drop does not need to be fully extended. The Dual-Tension system applies tension both horizontally and vertically to keep the projection surface evenly tensioned and flat. If required, the vertical tension can be retensioned and optimally adjusted to the selected extension height. This allows the desired drop height to be freely selected without compromising the flatness of the projection surface.

Power connection & Plug & Play

Power connection & Plug & Play: Viewed from the front, the power connection is on the right side of the screen housing. The TXN series has a standard IEC 60320 C14 appliance inlet and comes with a detachable 5 m power cable. The screen end has a 90° angled IEC 60320 C13 connector; the wall-socket end has a 90° angled grounded Schuko plug (CEE 7/7, Type E/F). The cable can be replaced with a compatible standard IEC power cable if needed. No hardwiring or electrician is required: mount the screen and plug it in. For discreet routing to a socket on the left, a cable duct can be installed behind the housing; the supplied cable is long enough for this.

Care & cleaning

The screen surface is easy to maintain and can be cleaned when necessary. Dust can be removed with a soft duster or cloth. More persistent dirt or grease marks can be wiped carefully with a soft, damp cloth. If necessary, a mild, neutral cleaner can also be used.

Seamless one-piece projection surface

The projection fabric is made from one continuous piece of material. There are no joined, welded or sewn sections within the visible projection area, so there are no distracting seam or brightness lines. This keeps the image homogeneous and visually consistent across the entire surface.

Suitable for / Not recommended for / Alternatives

Suitable for:

  • Standard-throw and long-throw projectors
  • Home cinema and living rooms
  • Users who want a better black level than with a white screen
  • Rooms with moderate residual light
  • UST projectors when dedicated CLR performance is not required
  • 3D Compatible: Suitable for active 3D projection with compatible projectors and shutter glasses.

Not recommended for:

  • UST / Laser TV when maximum CLR performance and stronger ambient-light rejection are required
  • RGB triple-laser projectors when laser speckle is the main issue

Alternatives:

  • RGB triple-laser / speckle reduction: HiViGrey Cinema 3L
  • Stronger contrast in residual light: HiViGrey Cinema 5D/HDR
  • UST / Laser TV: HiViPrism Cinema HDR CLR
Variants: Aspect Ratio, Casing Color & Warranty

Please choose your variant:

  • Aspect Ratio: 16:9 HD Widescreen or 21:9 Cinemascope
  • Casing Color: Black or White
  • Warranty: 2 years or 5 years (optional)

HiViLux - HighEnd AudioVideo Technology

For more than 15 years, HiViLux has developed premium audio and video products for demanding home cinema applications.

specification
specification
x
Specification
Screen materialHiViGrey Cinema 0,8
Gain0.8
Viewing angle165°
Max. resolution8K
For projectorLong/Standard Throw · Triple-Laser(RGB) · LCoS(SONY/JVC) · UST · DLP · Laser · 3LCD · LED
Optimized forMatte graue Basis (verbesserter Schwarzwert)
AcousticsNicht akustisch transparent
3D playbackYes
Black backingYes
Codehivigrey08
Short featureHiViGrey Cinema 0,8/Matte grau
Housing
BrandHiViLux
SeriesTXN
Colorgloss white · matte black
MaterialALU
Mountingwall · ceiling
Remote controlRF radio
OptionalIR set · RF Switch-Trigger · 2-way control unit · Smart Home set
Short featureDual-Tension-Motorleinwand TXN Serie
Sample order
Sample order
x
SAMPLE REQUEST

Feel the Difference – Request Screen Fabric Samples

Tell us your exact projector model, image size, viewing distance, room lighting and wall colours. We personally recommend suitable fabrics and explain both advantages and possible limitations.

Shipping: Sample requests shipped outside Germany cost €5, fully credited towards a later screen purchase. In Germany, the first sample request per customer is complimentary, including postage; further requests cost €5 and are also fully creditable. Shipped by Deutsche Post: usually 1–2 business days within Germany, 2–3 abroad after dispatch (non-binding estimates). Samples do not need to be returned.

  • Professional fabric advice, including possible disadvantages
  • Deutsche Post delivery; keep the samples
  • No obligation to purchase
Sample service: €5 outside Germany, fully credited towards a later screen purchase. First request in Germany complimentary once per customer.

Your information will only be used to process your sample request. Further information can be found in our Privacy Policy .

Close-up of an original projection screen fabric sample
Installation
Installation
x

Installation

Here you will find the matching PDF manual for your product.

PDF Manual
Individually
Individually
x
CUSTOM DESIGN

Your Screen – as Unique as Your Home Theater

Do you have specific requirements for size, shape, screen fabric, or frame accents? We will craft your screen exactly to your specifications – so it fits your room perfectly.

  • Custom sizes & formats
  • Wide selection of fabrics & frame colors
  • Consultation & visualization before production
We will get back to you within 1–2 business days with an offer.
Example of a custom screen design
